IIHS rollover test?

Sean L

Well-Known Member
First Name
Sean
Joined
Mar 9, 2018
Messages
24,624
Reaction score
121,842
Location
North Carolina
Vehicle(s)
2018 Jeep Wrangler Sahara, 2017 Honda Accord Sport, 2003 Yamaha V Star 650 Silverado, 2014 Yamaha V Star 1300 Tourer
Occupation
Retired Marine, Construction Estimator
Vehicle Showcase
2
This ignore feature works out pretty well now that I've actually used it. :)


four low

Well-Known Member
Joined
Feb 1, 2017
Messages
1,697
Reaction score
1,730
Location
central New York
Vehicle(s)
2018 JL
Back to JL Bashing, a relief from "he said " bashing ; if the JK passed this test, lets see that test video, and damage aftermath, and compare the two.
The frame flare out, and suspension component attachment points " may " have caused the lift, and roll.


Sean L

Well-Known Member
First Name
Sean
Joined
Mar 9, 2018
Messages
24,624
Reaction score
121,842
Location
North Carolina
Vehicle(s)
2018 Jeep Wrangler Sahara, 2017 Honda Accord Sport, 2003 Yamaha V Star 650 Silverado, 2014 Yamaha V Star 1300 Tourer
Occupation
Retired Marine, Construction Estimator
Vehicle Showcase
2
Back to JL Bashing, a relief from "he said " bashing ; if the JK passed this test, lets see that test video, and damage aftermath, and compare the two.
The frame flare out, and suspension component attachment points " may " have caused the lift, and roll.
The JK comes close to tipping, but not quite. There is more cabin intrusion than the JL though



Sean K.

Well-Known Member
First Name
Sean
Joined
Jul 24, 2018
Messages
2,940
Reaction score
3,537
Location
AZ
Vehicle(s)
JLUR, TJ, 4Runner, Cummins tow rig, 2 Tube Frame Buggies, Lotus SC Elise, Mazda 3, RAV4 Hybrid
Yes, but not all ladder frames are identical. Here's a Ram 1500 frame vs the Wrangler frame for reference.





You'll note in the slow motion portions of the IIHS video of the wrangler that the tipover does not begin until the vehicle hits that point where the frame widens out. A better bumper could help out in this situation I'm sure, but the shape of the Jeep's frame does appear to be a contributing factor.
It's an IFS frame and it is still narrower in front than at midship.

But whatever...if you think that's what caused the tip over, you don't need my permission and frankly, this whole thread is much ado about nothing.


Sean L

Well-Known Member
First Name
Sean
Joined
Mar 9, 2018
Messages
24,624
Reaction score
121,842
Location
North Carolina
Vehicle(s)
2018 Jeep Wrangler Sahara, 2017 Honda Accord Sport, 2003 Yamaha V Star 650 Silverado, 2014 Yamaha V Star 1300 Tourer
Occupation
Retired Marine, Construction Estimator
Vehicle Showcase
2
It's an IFS frame and it is still narrower in front than at midship.

But whatever...if you think that's what caused the tip over, you don't need my permission and frankly, this whole thread is much ado about nothing.
Yes but IFS shouldn't make a difference in what I'm talking about. the Ram's frame is wider at the front meaning it takes more of an impact in a small overlap test. Flaring out the frame could help in this instance, but that would prevent using a stubby aftermarket bumper. The frame shape isn't the only cause but It contributes. Its the price we pay for the off road capability. For what its worth it does a good job keeping the cabin intact and that's where it counts.


Sean K.

Well-Known Member
First Name
Sean
Joined
Jul 24, 2018
Messages
2,940
Reaction score
3,537
Location
AZ
Vehicle(s)
JLUR, TJ, 4Runner, Cummins tow rig, 2 Tube Frame Buggies, Lotus SC Elise, Mazda 3, RAV4 Hybrid
Yes but IFS shouldn't make a difference in what I'm talking about. the Ram's frame is wider at the front meaning it takes more of an impact in a small overlap test. Flaring out the frame could help in this instance, but that would prevent using a stubby aftermarket bumper. The frame shape isn't the only cause but It contributes. Its the price we pay for the off road capability. For what its worth it does a good job keeping the cabin intact and that's where it counts.
A 2WD Ram 1500 isn 't going to run a larger diameter tire like even an IFS 4WD would....which means it doesn't need to have the frame come in as much.


Sean L

Well-Known Member
First Name
Sean
Joined
Mar 9, 2018
Messages
24,624
Reaction score
121,842
Location
North Carolina
Vehicle(s)
2018 Jeep Wrangler Sahara, 2017 Honda Accord Sport, 2003 Yamaha V Star 650 Silverado, 2014 Yamaha V Star 1300 Tourer
Occupation
Retired Marine, Construction Estimator
Vehicle Showcase
2
A 2WD Ram 1500 isn 't going to run a larger diameter tire like even an IFS 4WD would....which means it doesn't need to have the frame come in as much.
Except that frame I showed was a 4x4. Notice how it still flares out in the front and gives a wider area for it to take an impact. For this specific test, the Jeep's frame just doesn't take any of the impact until the vehicle passes the point behind the front axle. A stronger bumper could be a good answer to this test as that stock bumper doesn't have much behind the plastic.

And in no way am I advocating IFS as a better off roader, before anyone thinks I am, lol.


Sean K.

Well-Known Member
First Name
Sean
Joined
Jul 24, 2018
Messages
2,940
Reaction score
3,537
Location
AZ
Vehicle(s)
JLUR, TJ, 4Runner, Cummins tow rig, 2 Tube Frame Buggies, Lotus SC Elise, Mazda 3, RAV4 Hybrid
Except that frame I showed was a 4x4. Notice how it still flares out in the front and gives a wider area for it to take an impact. For this specific test, the Jeep's frame just doesn't take any of the impact until the vehicle passes the point behind the front axle. A stronger bumper could be a good answer to this test as that stock bumper doesn't have much behind the plastic.

And in no way am I advocating IFS as a better off roader, before anyone thinks I am, lol.
Mea Culpa. Didn't notice the drive axle.

You're right that flaring out the very front of the frame would help in this specific accident test.....and then people would have to cut it off b/c it would fuck your approach angle (and limit the diameter tire you could clear). I wouldn't be surprised if this is the route Jeep decides to take.

Same thing happens on Toyota's cab mounts in front of the front door....and people have to cut them down and plate them in.


Sean L

Well-Known Member
First Name
Sean
Joined
Mar 9, 2018
Messages
24,624
Reaction score
121,842
Location
North Carolina
Vehicle(s)
2018 Jeep Wrangler Sahara, 2017 Honda Accord Sport, 2003 Yamaha V Star 650 Silverado, 2014 Yamaha V Star 1300 Tourer
Occupation
Retired Marine, Construction Estimator
Vehicle Showcase
2
Mea Culpa. Didn't notice the drive axle.

You're right that flaring out the very front of the frame would help in this specific accident test.....and then people would have to cut it off b/c it would fuck your approach angle (and limit the diameter tire you could clear). I wouldn't be surprised if this is the route Jeep decides to take.

Same thing happens on Toyota's cab mounts in front of the front door....and people have to cut them down and plate them in.
All true, there will always be mods. I think I'm more in favor of a stronger bumper or a cross brace type of reinforcement. A lot of bumpers get swapped out anyway so modded rigs might not have an issue. That is without taking a higher center of gravity from a lift and bigger tires into account.

Last edited:

Paluss

Well-Known Member
Joined
Feb 15, 2018
Messages
315
Reaction score
274
Location
maryland
Vehicle(s)
2018 Rubicon, 2013 Porsche 911, 2015 Harley CVO Streetglide
One thing I noticed in comparing the JK and JL videos is the driver side front tire does different things. On the JK it gets crushed on the metal pillar deflates and moves out of the way, On the JL it does not hit the pillar and somehow gets pushed under the frame which may contribute to the rollover, hard to tell if it has blow out.

Interesting that FCA sent a second vehicle and got same result, or maybe the second vehicle was a bribe and they were not smart enough to know that and crashed it too. just kidding:LOL::LOL:

OP
rickinAZ

rickinAZ

Well-Known Member
First Name
Rick
Joined
Jan 2, 2020
Messages
911
Reaction score
754
Location
Phoenix
Vehicle(s)
2021 Rubicon Diesel (in transit) 2016 Rubicon Hard Rock 2-door (just sold)
Occupation
Retired
  • Thread starter
  • Thread Starter
  • #57
I don't know why we're worrying about rolling over. I'm a big proponent of the two JL safety packages, but as the Luddites on this forum say, "just pay attention" and you won't need them. Same applies to rollovers; if we'd just pay better attention, we wouldn't care about crashworthiness.

just kidding :)


Chocolate Thunder

Well-Known Member
Joined
Feb 20, 2018
Messages
2,670
Reaction score
3,510
Location
Texas
Vehicle(s)
2019 Wrangler Unlimited Rubicon
I don't know why we're worrying about rolling over. I'm a big proponent of the two JL safety packages, but as the Luddites on this forum say, "just pay attention" and you won't need them. Same applies to rollovers; if we'd just pay better attention, we wouldn't care about crashworthiness.

just kidding :)
I wish I could see that exact same crash recreated with the emergency braking feature utilized. That would be great. Judging by the crash I believe with all my heart, soul, and mind that the Jeep absolutely would not have rolled over because the braking would reduce the speed tremendously prior to the impact. I just wish I could see how much. Still totaled? Doubt it. Fender bender? Maybe.


Wranglernator

Well-Known Member
Joined
Aug 17, 2019
Messages
60
Reaction score
65
Location
SoCal
Vehicle(s)
1991 Wrangler (sold); 2021 Sting Gray Rubi Unlimited on the way
Occupation
Evil Overlord
One thing I noticed in comparing the JK and JL videos is the driver side front tire does different things. On the JK it gets crushed on the metal pillar deflates and moves out of the way, On the JL it does not hit the pillar and somehow gets pushed under the frame which may contribute to the rollover, hard to tell if it has blow out.

Interesting that FCA sent a second vehicle and got same result, or maybe the second vehicle was a bribe and they were not smart enough to know that and crashed it too. just kidding:LOL::LOL:
This. It's the wheel tunneling under the JL that makes it roll. A much easier fix than redesigning the chassis.

This test was done with a Sport right? I wonder if the Rubicon with its obviously more robust axle, linkage, and suspension would do the same.


jeepdabest

Well-Known Member
First Name
Bobby
Joined
Mar 27, 2019
Messages
741
Reaction score
912
Location
Arizona
Vehicle(s)
2019 JL Sahara
The next generation Wrangler (JM) is already undergoing safety testing with new airbags made in Wuhan, China on the menu.
giphy - 2020-05-15T191902.452.gif
