Driver side area wiring question

[AC77]

Hello everyone. Does anyone have a diagram for which of the driver side footwell area may have an ACC/switched power and a constant power ? Thank you in advance

Sponsored



[nositting]

i don’t, sorry. i think most take from the dash 12v outlet or the one in the trunk. i think one is battery and the other is keyed as per the diagrams on their covers. also to note is that i believe there is a pretty cheap amazon product that serves as a splitter - you unplug the outlet and plug it back into the splitter and then you have a free end to connect to whatever you want to power. i’m sure someone else can explain this better, lol



[vetygud]

I have the four switched accessory circuits in the passenger's foot well or under the hood on the passenger's side by the battery. They can be programmed for ignition or hot. Two are 40 amp and the others are 15 amp.



[AC77]

i don’t, sorry. i think most take from the dash 12v outlet or the one in the trunk. i think one is battery and the other is keyed as per the diagrams on their covers. also to note is that i believe there is a pretty cheap amazon product that serves as a splitter - you unplug the outlet and plug it back into the splitter and then you have a free end to connect to whatever you want to power. i’m sure someone else can explain this better, lol

Thank you



[AC77]

I have the four switched accessory circuits in the passenger's foot well or under the hood on the passenger's side by the battery. They can be programmed for ignition or hot. Two are 40 amp and the others are 15 amp.

You mean the Aux switch wiring ? That I’m aware and are all in use ..
