Shock Upgrade

areuriding

Well-Known Member
First Name
Ken
Joined
Aug 20, 2021
Threads
11
Messages
350
Reaction score
304
Location
Manassas Park Va.
Vehicle(s)
2021 Wrangler Rubicon XR
New 2021 Rubicon 4 door XR looking to upgrade from factory shocks. Do I choose something that is for 0-2" lift? None are specific for the XR package.
Thanks for any help..... Ken



Omotose

Well-Known Member
First Name
Frank
Joined
Sep 24, 2021
Threads
12
Messages
74
Reaction score
142
Location
AZ Desert
Vehicle(s)
2021 Rubicon Unlimited Extreme Recon
I’m in the same boat. I’ll keep track of this thread.


AnnDee4444

Well-Known Member
Joined
Jan 14, 2019
Threads
37
Messages
3,626
Reaction score
4,408
Location
Earth
Vehicle(s)
Jeep
Choose the shocks based off of collapsed length. You want the shock to be less than or equal to the lengths below. The closer you are to the exact number, the less wasted shock stroke.

Front collapsed length = 17.25"
Rear collapsed length = 19"

This is the best info I have for the XR's factory shocks, but it may be possible to go slightly longer. Someone with an XR will need to verify by removing the shocks & bump stops, then compressing the suspension and measuring the eye-to-eye lengths.

Last edited:

Vrrooom

Well-Known Member
Joined
Aug 3, 2021
Threads
3
Messages
139
Reaction score
542
Location
Virginia
Vehicle(s)
2021 JLUR
I have an XR that I upgraded to Fox 2.0 shocks. I ordered the one for 0-1.5” lift and it worked perfectly. Full stuff still has a little more room for the shock, and under full droop it allows for a little more travel without maxing out any brake lines etc.

OP
OP

areuriding

Well-Known Member
First Name
Ken
Joined
Aug 20, 2021
Threads
11
Messages
350
Reaction score
304
Location
Manassas Park Va.
Vehicle(s)
2021 Wrangler Rubicon XR
I have an XR that I upgraded to Fox 2.0 shocks. I ordered the one for 0-1.5” lift and it worked perfectly. Full stuff still has a little more room for the shock, and under full droop it allows for a little more travel without maxing out any brake lines etc.
Awesome.. Thanks!
