Rim width plays a major factor in contact area
Exactly. So does vehicle weight, driving altitude, air temperature, etc. Just like picking the right gear ratio, there are so many factors to consider that there is NOT a one size fits all when it comes to PSI for a specific tire size no matter how much @CarbonSteel wants it to be his way or the highway.



Vinman

Well-Known Member
First Name
Vince
Joined
Oct 19, 2020
Threads
22
Messages
598
Reaction score
1,379
Location
Calgary, Alberta
Vehicle(s)
2021 JLU Rubicon
FWIW,
I ran 15x8” rims with 12.50 wide KO or KO2 tires on all my previous TJ’s and have never had full contact tread unless tire pressure was ridiculously low, like sub 20 psi.
I always ran around 26 psi on those Jeeps.


JEEP4U

Well-Known Member
First Name
Richard
Joined
Oct 4, 2021
Threads
14
Messages
367
Reaction score
367
Location
307
Vehicle(s)
2021 Jeep Wrangler
Not a fan of the K02...........they are horrible in mud !!!

But, I run my 40" Maxxis Razr AT at 34 cold.


CarbonSteel

Well-Known Member
Joined
Jul 21, 2019
Threads
228
Messages
3,502
Reaction score
4,485
Location
Colorado
Vehicle(s)
2019 Jeep Rubicon Unlimited
Vehicle Showcase
1
Exactly. So does vehicle weight, driving altitude, air temperature, etc. Just like picking the right gear ratio, there are so many factors to consider that there is NOT a one size fits all when it comes to PSI for a specific tire size no matter how much @CarbonSteel wants it to be his way or the highway.
LOL - not at all--it is more about confirming facts and data. Given that most people who have posted here that 37" K02 tires do not have full contact at 30PSI, unless you are running really wide wheels, having it at 35PSI seems less than probable.

EDIT - My JLUR weighs 5970 and therefore would be more likely to have full contact patch versus lighter Jeeps and it does not even at 30PSI on 17x8.5" wheels and they are Load Range C which means software sidewalls so there is that...

Last edited:

TheAmericanB

Member
First Name
Brandon
Joined
Jun 17, 2022
Threads
0
Messages
8
Reaction score
26
Location
CO -> NC
Vehicle(s)
2023 JLUR XR
My ‘23 JLURXR came from the factory last week with 45 psi in all the 35s! 🤯



No IFS

Well-Known Member
Joined
Nov 13, 2019
Threads
10
Messages
1,051
Reaction score
1,960
Location
So Cal
Vehicle(s)
JL Rubicon
Every combination is different. Do the chalk or water test to determine your correct pressure. Tire pressures are listed as guides for legal reasons. The tires fit many different vehicles.


kah.mun.rah

Well-Known Member
First Name
Merenkahre Jr.
Joined
May 16, 2022
Threads
13
Messages
912
Reaction score
1,515
Location
Duat
Vehicle(s)
2021 Wrangler Unlimited Rubicon
Every combination is different. Do the chalk or water test to determine your correct pressure. Tire pressures are listed as guides for legal reasons. The tires fit many different vehicles.
⬆ this


gato

Well-Known Member
Joined
Apr 4, 2021
Threads
17
Messages
1,147
Reaction score
1,702
Location
New England
Vehicle(s)
2021 JLUR
Not just for Jeeps, but the tire pressures in the door sticker by the manufacturer these days are set up mostly for fuel economy reasons. They are typically set up as the maximum pressure they can get away with, without a massive impact on ride and handling qualities.

For most vehicles these days from Jeeps to sports cars, running a pressure lower than the door sticker provides much better ride and handling.

For very high profile tires, like on the Jeep, pothole performance is not much of an issue, so experiment and set a tire pressure that gives you the best ride, while not rolling too much on corners to affect handling.

For KO2s I've found that on a very heavy 4-door, 28-30 works great for 37R17 and 30 works great for 33R17.



OP
OP
jeme

jeme

Well-Known Member
First Name
John
Joined
Jul 6, 2020
Threads
22
Messages
378
Reaction score
185
Location
Florida
Vehicle(s)
TBD
Can anyone post a pic of what the factory sticker is on a Rubicon with 285/70/17 KO2's? Everyone is reporting 37 and that is what I am tending to go with.


kah.mun.rah

Well-Known Member
First Name
Merenkahre Jr.
Joined
May 16, 2022
Threads
13
Messages
912
Reaction score
1,515
Location
Duat
Vehicle(s)
2021 Wrangler Unlimited Rubicon
Can anyone post a pic of what the factory sticker is on a Rubicon with 285/70/17 KO2's? Everyone is reporting 37 and that is what I am tending to go with.
Here you go but as others have mentioned, best to run a chalk or other test to see what is best for your setup.



CarbonSteel

Well-Known Member
Joined
Jul 21, 2019
Threads
228
Messages
3,502
Reaction score
4,485
Location
Colorado
Vehicle(s)
2019 Jeep Rubicon Unlimited
Vehicle Showcase
1
Out of curiosity, has anyone determined what PSI (generally speaking) it takes for full tread contact on 37" K02's?

I have to deflate into the mid-20PSI range for that with LRC 37" K02's on 17x8.5" wheels. Others?


kah.mun.rah

Well-Known Member
First Name
Merenkahre Jr.
Joined
May 16, 2022
Threads
13
Messages
912
Reaction score
1,515
Location
Duat
Vehicle(s)
2021 Wrangler Unlimited Rubicon
Out of curiosity, has anyone determined what PSI (generally speaking) it takes for full tread contact on 37" K02's?

I have to deflate into the mid-20PSI range for that. Others?
On my 2021 JLUR with 37x12.5R17 BFG KO2, 18K miles of wear on the tread, 17x8.5 TeraFlex Nomad wheels, and one occupant weighing 205 lbs, the results of a chalk test and an ARB Digital tire pressure gauge at sea elevation, 75 degrees outside with a slight wind from the south-west, my best wear pattern came in at an average of 35psi.

That said, there is not a one size fits all and rather than relying on the results of other peoples' experiments I recommend that readers do their own chalk (or other) test to see what works best for their setup and environment. One more note, a regular rotation of your tires is just as important as PSI if you want to extend the life of your tire.

All of this said, if you are like me and the trail damage and/or desire to upgrade your tire size come into play before your tread is gone anyway, just run the PSI that feels best for your driving comfort.


CarbonSteel

Well-Known Member
Joined
Jul 21, 2019
Threads
228
Messages
3,502
Reaction score
4,485
Location
Colorado
Vehicle(s)
2019 Jeep Rubicon Unlimited
Vehicle Showcase
1
On my 2021 JLUR with 37x12.5R17 BFG KO2, 18K miles of wear on the tread, 17x8.5 TeraFlex Nomad wheels, and one occupant weighing 205 lbs, the results of a chalk test and an ARB Digital tire pressure gauge at sea elevation, 75 degrees outside with a slight wind from the south-west, my best wear pattern came in at an average of 35psi.

That said, there is not a one size fits all and rather than relying on the results of other peoples' experiments I recommend that you do your own chalk (or other) test to see what works best for your setup and environment.
Right--I have and posted those results above so thanks for your input.

Curious as to what PSI others have had to go to gain full tread contact.
