5680 lbs without cargo/passengers...

JeepinJason33

Well-Known Member
Joined
Oct 3, 2020
Messages
495
Reaction score
455
Location
Denver
Vehicle(s)
2021 JLU Rubicon V6 with Etorque - just starting build. 2019 Grand Cherokee SRT, 2001 XJ mild build, 97 TJ supercharged, Atlas, cage, 1 tons, OBA etc. 83 Cherokee Chief Restored
Spotted a scale while out driving around and decided to weigh in. Was surprised to see that I was already at 5680 lbs. without anyone in the vehicle or cargo. The gas tank was about 3/4 full. I could easily exceed 6000 pounds with myself and one other person in the vehicle and a few tools. Hard top is probably 100 pounds additional weight when I am driving around during the winter... These things get over GVWR quickly, glad I went down to 5.13 gears.

List of mods that added measurable weight:
37" BFG KM3 on KMC bead locks
3.5 Gamechanger MC lift
MC steering system
MC Full underbelly skids
MC rear diff skid
RC front diff skid
Adams 1350 front driveshaft
Rockhard front and rear control arm skids
ARB rear diff cover
ARB twin compressor
ACE rock rails
ACE front bumper
ACE rear bumper
ACE stand alone tire carrier
ACE hi-lift carrier and hi-lift
Warn winch with synthetic line



Advertisement


OP
OP
JeepinJason33

JeepinJason33

Well-Known Member
Joined
Oct 3, 2020
Messages
495
Reaction score
455
Location
Denver
Vehicle(s)
2021 JLU Rubicon V6 with Etorque - just starting build. 2019 Grand Cherokee SRT, 2001 XJ mild build, 97 TJ supercharged, Atlas, cage, 1 tons, OBA etc. 83 Cherokee Chief Restored
I'd beef up the brakes if I were you.
Agree, the brakes seem to be the weak point right now as it takes noticeably longer to stop. I may end up just replacing the axles with Dana 60's as they come with the bigger brakes.


Heimkehr

Well-Known Member
First Name
James
Joined
Sep 3, 2020
Messages
1,341
Reaction score
2,425
Location
Pennsylvania
Vehicle(s)
2021 Jeep Wrangler Unencumbered
Spotted a scale while out driving around and decided to weigh in. Was surprised to see that I was already at 5680 lbs. without anyone in the vehicle or cargo.

That's a lotta Jeep. Perilously close to three tons before butts and boxes.

Here, 6K earns me a third window sticker (Weight Class 2), and my annual registration fee would double. Voice of experience; my Wrangler's predecessor was a truck.

OP
OP
JeepinJason33

JeepinJason33

Well-Known Member
Joined
Oct 3, 2020
Messages
495
Reaction score
455
Location
Denver
Vehicle(s)
2021 JLU Rubicon V6 with Etorque - just starting build. 2019 Grand Cherokee SRT, 2001 XJ mild build, 97 TJ supercharged, Atlas, cage, 1 tons, OBA etc. 83 Cherokee Chief Restored
That's a lotta Jeep. Perilously close to three tons before butts and boxes.

Here, 6K earns me a third window sticker (Weight Class 2), and my annual registration fee would double. Voice of experience; my Wrangler's predecessor was a truck.
Yeh, will probably replace the MC underbelly skids with the aluminum ones that get rid of the gas tank skid as well. Don't want to replace all the bumpers with aluminum though. Jeep still handles fine and I am the only one that drives it.


aldo98229

Well-Known Member
First Name
Aldo
Joined
Nov 16, 2019
Messages
5,244
Reaction score
11,397
Location
Bellingham, WA
Vehicle(s)
2018 Jeep Wrangler Unlimited Sahara, 2018 Fiat 124 Spider Abarth
Occupation
Market Research
Vehicle Showcase
2
You are likely carrying 650 lbs in wheels, tires and oversized carrier alone!

Each 37-inch KM3 weighs 78 lbs x 5 = 390
Each aftermarket wheel weighs ~ 33 lbs x 5 = 165
Oversized spare carrier, high lift jack...? Another 100 lbs...?

Geez. I’d hate to get a flat! 😫


PacNWJLGecko

Banned
Banned
First Name
Chad
Joined
May 9, 2021
Messages
255
Reaction score
265
Location
Pacific NW
Vehicle(s)
2021 JL
That's a lotta Jeep. Perilously close to three tons before butts and boxes.

Here, 6K earns me a third window sticker (Weight Class 2), and my annual registration fee would double. Voice of experience; my Wrangler's predecessor was a truck.
Where's here?


sourdough

Well-Known Member
First Name
Strider
Joined
Nov 12, 2017
Messages
1,313
Reaction score
2,788
Location
93013
Vehicle(s)
white JLR
Build Thread
Link
Occupation
wanderer
Vehicle Showcase
1
It's hard to make big weight savings and have quality wheels and tires. OPs listed Ace metal items is the problem. JLU owners have a selection of aluminum parts that make JL owners envious. But beware some companies aluminum parts are't all that much lighter.


track.n.trail

Well-Known Member
First Name
Owen
Joined
Jun 15, 2020
Messages
156
Reaction score
138
Location
San Francisco
Vehicle(s)
2020 JLUR
Occupation
Engineer
I'd beef up the brakes if I were you.
I'm on a similar setup (37" KM3s, lots of armor, and a full fridge setup) and I still think the brakes are pretty adequate. A bit more pedal pressure is needed during everyday driving but during a full emergency stop the brakes do a good job hauling the Jeep down.


Heimkehr

Well-Known Member
First Name
James
Joined
Sep 3, 2020
Messages
1,341
Reaction score
2,425
Location
Pennsylvania
Vehicle(s)
2021 Jeep Wrangler Unencumbered
OP
OP
JeepinJason33

JeepinJason33

Well-Known Member
Joined
Oct 3, 2020
Messages
495
Reaction score
455
Location
Denver
Vehicle(s)
2021 JLU Rubicon V6 with Etorque - just starting build. 2019 Grand Cherokee SRT, 2001 XJ mild build, 97 TJ supercharged, Atlas, cage, 1 tons, OBA etc. 83 Cherokee Chief Restored
You are likely carrying 650 lbs in wheels, tires and oversized carrier alone!

Each 37-inch KM3 weighs 78 lbs x 5 = 390
Each aftermarket wheel weighs ~ 33 lbs x 5 = 165
Oversized spare carrier, high lift jack...? Another 100 lbs...?

Geez. I’d hate to get a flat! 😫
Weight above is probably right, but don't forget that is not all plus weight, the OEM wheels and tires probably weigh 450.

Yes, the ACE stuff is heavy, but I have had aluminum bumpers before on my TJ. They were not that much lighter and cost a ton more once you include powder coating. These ACE bumpers are beefy, but take one hell of a hit without denting at all.
